Great For Home Care or Ambulatory Treatment Medical Syringe Pump With Syringe Size 1ml-20ml 180g Weight Only

Categories	Medical Infusion Pump
Properties:	Medical Materials & Accessories
Brand Name:	BIO
Model Number:	AJ5805
Place of Origin:	China
MOQ:	1 unit
Delivery Time:	7 working - days since getting full payment
Payment Terms:	Credit card, Paypal, T/T
Supply Ability:	500 units / month
Packaging Details:	Carton (20105cm) 0.5kg
Syringe Size:	1ml - 20ml Single-use Syringe
Infusion Rate:	1mm/hr - 99mm/hr
Alarms:	Battery Depleted, Mechanical Error, Occlusion, Syringe Disengaged, Completion
Alerts:	Battery Low, Syringe Not Loaded, Near End
OLED Display:	Syringe Size; Rate Is Set By Mm/hr And Displayed In Ml./hr Simultaneously; Alarm Messages
Maximum Infusion Pressure:	≤ 0.12MPa（with 10 Ml Syringe）
Dimension:	166 (L) x 60 (B) x 30 (H) mm
Weight:	≤ 180g (battery Weight Not Included)

Contact Now

Add to Cart

Great For Home Care or Ambulatory Treatment Medical Syringe Pump With Syringe Size 1ml-20ml 180g Weight Only

AJ5805 portable syringe pump is accurate, reliable infusion solution for Thalassemia (desferral) treatment,

pain management, neonatal care and many other ambulatory treatment with low rate small volume.

It’s compatible with any brand syringe from 1 to 20ml and is programmable in mm/h.

The pump can also automatically convert & display the ml/hr rate based on mm/h rate of the calibrated syringe.

Specifications

1	Syringe Size	1 ml - 20 ml single-use syringe
2	Infusion Rate	1 mm/hr - 99 mm/hr
3	Alarms	Battery Depleted, Mechanical Error, Occlusion Syringe Disengaged, Completion.
4	Alerts	Battery Low, User Prompt, Syringe Not Installed, Near End
5	Accuracy	± 2 %
6	Bolus Volume	No limit, min. 0.1 ml
7	PCA Function	When the flow rate number is lower than ½ of the syringe size, P.C.A. Function can be enabled. Each bolus is ¼ of current hourly volume, with 30 min locking interval
8	OLED Display	Syringe size; rate is set by mm/hr and displayed in ml/hr simultaneously; alarm messages, run- ning status.
9	“LOW BATT” LED Indicator	Flashing yellow/red indicator when battery is low or depleted
10	Maximum Infusion Pressure	≤ 0.12 MPa (with 10 ml syringe)
11	Occlusion Alarm Pressure	0.12 MPa (with 10 ml syringe)CE 0197, IEC 60601
12	Safety Approvals	CE 0197, IEC 60601 - 1 - 8: 2003, Type CF, IPX1
13	Battery Size	AA x 3
14	Dimensions	166(W) x 60(D) x 30(H) mm
15	Weight	≤ 180g (battery weight not included)

Applications

1	Thalassemia
2	Parkinson (Apokinon) etc.
3	Neonatal Care
4	Immunity Deficiency (Globulin)
5	Chemotherapy
6	Pain Management
7	Epidural Treatment

Safety & Accessories

1	Alarm Indicators	An immediate identification of pump’s alarm and alert messages.
2	Bolus Cable (PCA)	Patient can push Bolus button to add extra dos-age for quick relief of pain. (Maximum 1 push every 30 minutes for safety).
3	Bright OLED Screen	Bright & Engergy saving OLED screen displays both infusion rate and alarm message.
4	Carrying Bag	The carrying bag comes with programmable lock and exit for the PCA cable and IV line for patient.
5	Syringe Cover	Protects the syringe during the infusion to guarantee the safe & accurate infusion.
6	Package Contents	The complete package includes a carrying bag with programmable lock for ambulatory use, syringe covers, operating instruc- tions and a set of batteries.

Easy of Use

1	Lightweight and compact.
2	Digital programming with a bright OLED screen.
3	Clear display of current infusion rate and alarm message.
4	Powered by 3 X AA batteries
