Name: 2017 T4 Aluminum Solid Round Bar High Strength Fair Workability For Aerospace Components
Brand: HUANYU
Price: 1 USD

Home > Aluminum Bars >

2017 T4 Aluminum Solid Round Bar High Strength Fair Workability For Aerospace Components

Categories	Aluminium Solid Round Bar
Brand Name:	HUANYU
Model Number:	HYRB2017T4
Place of Origin:	CHINA
MOQ:	1 METRIC TON
Price:	Negotiable
Payment Terms:	T/T
Supply Ability:	40 METRIC TON PER MONTH
Delivery Time:	40 DAYS
Packaging Details:	PLYWOOD CASE
Surface Treatment:	Mill Finish
Machining characteristics:	Good
Applications:	strength structural components, aircraft, machine construction, military equipment, rivets.
Welding:	suitable for welding only by resistance welding
Workability:	Fair

Contact Now

Add to Cart

Product Details
Company Profile

2017 T4 Aluminum Solid Round Bar High Strength Fair Workability For Aerospace Components

Aluminum 2017 is a heat treatable wrought alloy that offers decent strength, ductility, and good machinability. Aluminum 2017 offers more strength than Aluminum 2011, and has fair workability and corrosion resistance.

Aluminum 2017 Applications:

Aerospace components
Rivets
General structural components
Transportation
Fasteners
Screw machine products
Gauges
Pulleys
Needles for knitting

Aluminum 2017 chemical composition that consists of:

Al 91.5-95.5%
Cu 3.5-4.5%
Mn 0.4-1%
Fe 0.7% max
Mg 0.4-0.8%
Zn 0.25% max
Ti 0.15%
Cr 0.1%

Chemical Composition Limits
Weight%	Al	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Others Each	Other Total
2017 USA	Rem	0.20-0.8	0.7 max	3.5-4.5	0.40-1.0	0.40-0.8	0.10 max	0.25 max	0.15 max	0.05 max	0.15 max
Weight%	Al	Si	Fe	Cu	Mn	Mg	Cr	Zn	Zr + Ti	Others Each	Other Total
2017A EAA	Rem	0.20-0.8	0.7 max	3.5-4.5	0.40-1.0	0.40-1.0	0.10 max	0.25 max	0.25 max	0.05 max	0.15 max

Typical Mechanical Properties

Material	Condition	Tensile Strength (N/mm²) min		Yield Strength		Elongation in 4D %
		ksi	Mpa	ksi	Mpa
2017	2017-T4 Bar	55	379	32	221	12

Product Tags:

aluminium round rod

aluminium alloy billet

2017 T4 Aluminum Solid Round Bar High Strength Fair Workability For Aerospace Components
