| Categories | Fire Fighting Truck |
|---|---|
| Brand Name: | CXFIRE |
| Model Number: | SXF5190GXFSG80 |
| Certification: | CCC, CE, EN, NFPA |
| Place of Origin: | China |
| MOQ: | 1 Unit |
| Price: | USD115,000-USD135,000 |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Supply Ability: | 1000 units per year |
| Delivery Time: | 6 months |
| Packaging Details: | Standard Export Package and Delivery by Bulk Carrier or Ro-Ro Ship |
| Overall Dimension: | 8640*2500*3730mm |
| Total Weight: | 19400Kgs with Full Load |
| Chassis: | 4x2 Sinotruk HOWO T |
| Engine: | 248Kw |
| Cabin: | Double Cabin with 6 Seats |
| Superstructure: | Aluminum Alloy Welded Frame |
| Liquid Tank: | 8000L Water Tank & PP Material (Never Rust) |
| Water Pump: | 60L/s@10bar |
| Water Monitor: | 50L/s@10bar with 60m Shoot Range |
| Painting: | Red paint, U.S. PPG |
HOWO 8000L Water Tanker Fire Fighting Truck with Double Row Cabin
1. The Whole Fire Fighting Truck
| No. | Main Items | Technical Parameters |
| 1.1 | Model | SXF5190GXFSG80 |
| 1.2 | Overall Dimension | 8640*2500*3730mm |
| 1.3 | Full Load Weight | 19400kgs |
| 1.4 | Number of the Crew | 6 (include driver) |
| 1.5 | Max. Speed | 90km/h |
| 1.6 | Capacity | 8000L Water. PP composite material liquid tank (Never Rust) |
| 1.7 | Fire pump | 60L/s @ 10bar |
| 1.8 | Fire monitor | 50L/s flow rate, 60m shoot range |
| 1.9 | Painting | Red paint of U.S. PPG |
2. Chassis of the Fire Fighting Truck
| No. | Main Items | Technical Datasheet |
| 2.1 | Manufacturer | SINOTRUK |
| 2.2 | Model | Optional |
| 2.3 | Drive type | 4*2 |
| 2.4 | Wheelbase | 4700mm |
| 2.5 | Engine model | Optional (using German MAN engine technology) |
| 2.6 | Engine type | Inline 6-cylinder, turbocharged, inter-cooled diesel engine |
| 2.7 | Rated power | 248Kw |
| 2.8 | Gearbox | Manual gearbox, 9 forward gears + 1 reverse gear |
| 2.9 | PTO | Full power sandwich type, with additional cooling device |
| 2.10 | Fuel tank | 200L aluminum alloy round fuel tank |
| No. | Main Items | Technical Parameters |
| 3.1 | Cabin | |
| 3.1.1 | Structure | Double row cabin with 4 doors |
| 3.1.2 | Seats | 2+4, with 3-point safety belt, the rear 4 seats with SCBA bracket for 6-9L air cylinders, with storage box under the rear 4 seats |
| 3.2 | Standardized Sub-frame | |
| 3.2.1 | Material of Sub-frame | High-strength rectangular tube made of special steel |
| 3.2.2 | Performance | The liquid tank and the sub-frame are connected by elastic connecting seats |
| 3.3 | Compartment | |
| 3.3.1 | Material of Compartment | High-strength aluminum alloy profiles (Never Rust) |
| 3.3.2 | Structure | Aluminum alloy welded structure. Roof railing with LED light. With aluminum alloy ladder in the rear |
| 3.4 | Roller Shutter Door | |
| 3.4.1 | Material of Roller Shuter | Aluminum alloy profiles with anodized surface |
| 3.4.2 | Structure | With rain-proof groove on the top, lever-type bar, lock handle, pull strap, two-point fixed seat, LED light and sensors. |
| 3.5 | Foot Pedals | |
| 3.5.1 | Material of Pedals | High quality aluminum alloy |
| 3.5.2 | Structure | 50cm width, bear more than 300kg, anti-slip design, with double lock function. Mounted on the both sides of compartment. |
| 3.6 | Superstructure Electric Appliance | |
| 3.6.1 | Warning Light and Siren | Long-row warning light and siren are mounted above cabin. The controller is installed in the driver's cabin. |
| 3.6.2 | Strobe Light | Mounted on the both sides of the compartment |
| 3.6.3 | External Lighting | LED lights are mounted on the both sides of the compartment |
| 3.6.4 | Roof Lighting | LED lights are mounted on the inside of the roof |
| 3.6.5 | Side Indicator Light | Inline yellow warning light is mounted on the side of the compartment and pedals |
| 3.7 | Water Pump | |
| 3.7.1 | Brand | Optional |
| 3.7.2 | Model | Optional |
| 3.7.3 | Rated Flow Rate | 60L/s @ 10bar |
| 3.7.4 | Vacuum Pump | Electric vacuum pump |
| 3.7.5 | Priming Manner | Automatic |
| 3.7.6 | Suction Height | 7m |
| 3.7.7 | Priming Time | ≤50s |
| 3.7.8 | Location | Rear-mounted |
| 3.8 | Roof Fire Monitor | |
| 3.8.1 | Brand | Optional |
| 3.8.2 | Model | Optional |
| 3.8.2 | Flow Rate | 50L/s @ 10bar |
| 3.8.3 | Shoot Range | Water ≥ 60 m |
| 3.8.4 | Location | On the top of the tank |
| 3.8.5 | Control Manner | Manual |
| 3.8.6 | Horizontal Rotation | 0°~360° |
| 3.8.7 | Pitch Rotation Angle | -15°~60° |
| 3.9 | Liquid Tank | |
| 3.9.1 | Capacity | Water Tank 8000L |
| 3.9.2 | Material | PP composite material (Never Rust) |
| 3.9.3 | Structure | 1 Tank Manhole; 1 Overflow Device/Pressure Relief Device; 1 Liquid
Level Indicator; 1 Water tank Drain Outlets with Valves |
|
