| Categories | Brushless Alternator |
|---|---|
| Brand Name: | ACEPOW |
| Model Number: | BC184G |
| Certification: | CE,ISO |
| Place of Origin: | CHINA |
| MOQ: | 1 PCS |
| Price: | Negotiate |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 10000SETS/YEAR |
| Delivery Time: | 25 DAYS |
| Packaging Details: | CARTON BOX |
| Product name: | Brushless alternator |
| Model: | BC184G |
| Wire: | 100% Pure Copper Wire |
| Specification: | IECBS 5000, VDE 0530, IEC 34, NEMA MG1-22, CSA C2 |
| Package: | Strong Plywood |
| Structure: | Single Bearing or Double Bearing |
30KVA 24KW Brushless Alternator Brushless Synchronous AC Alternator Stamford Type Coupied With Engine
Specifications
1) Power range: 8-600kVA(6.5-536kw).
2) Brushless Synchronous A. C. Alternator,
3) Stamford& Leroy somer Type of Electric Generator,
4) Three Phase optional, IP23, Class H,
5) Rated voltage 400V, 110-690V option, and High-Voltage
Alternator(4KV&11KV) also available
FEATURES :
1. Any permanent magnetic generations,providing invariable
excitation on all occasions.
2. Easy to be connected with power network or other
generations.Standard 2/3 pitch windings check excessive midline
current.
3. Bala nced rotor with single or two sealed ball bearing.
4. Convenient installation and maintenance with easy access to
terminals,rotating diodes and coupling bolts
5. Wide range of Flange adaptor and single bearing coupling disc
6. Meet leading Industry and marine Standards
| Model | Prime Output (1500rpm/50Hz) 400V | Prime Output (1800rpm/60Hz) 440V | ||
| KVA | KW | KVA | KW | |
| AP-164A | 8.1 | 6.5 | 10.2 | 8.2 |
| AP-164B | 11 | 8.8 | 13.8 | 11 |
| AP-164C | 13.5 | 10.8 | 16.9 | 13.5 |
| AP-164D | 16 | 12.8 | 20 | 16 |
| AP-184E | 22.5 | 18 | 28.8 | 23 |
| AP-184F | 27.5 | 22 | 34.4 | 27.5 |
| AP-184G | 31.3 | 24 | 37.5 | 30 |
| AP-184H | 37.5 | 30 | 46.9 | 37.5 |
| AP-184J | 40 | 32 | 50 | 40 |
| AP-224C | 42.5 | 34 | 52.5 | 42 |
| AP-224D | 50 | 40 | 62.5 | 50 |
| AP-224E | 60 | 48 | 70 | 56 |
| AP-224F | 72.5 | 58 | 87.5 | 70 |
| AP-224G | 85 | 68 | 97.5 | 78 |
| AP-274C | 100 | 80 | 117.5 | 94 |
| AP-274D | 120 | 96 | 137.5 | 110 |
| AP-274E | 140 | 112 | 167.5 | 134 |
| AP-274F | 160 | 128 | 190 | 152 |
| AP-274G | 180 | 144 | 218.5 | 174.8 |
| AP-274H | 200 | 160 | 245 | 196 |
| AP-274J | 230 | 184 | 281 | 224.8 |
| AP-274K | 250 | 200 | 299 | 239.2 |
| AP-314C | 250 | 200 | 294 | 235 |
| AP-314D | 295 | 236 | 350 | 280 |
| AP-314E | 325 | 260 | 394 | 315 |
| AP-314F | 380 | 304 | 456 | 365 |
| AP-354C | 450 | 360 | 550 | 440 |
| AP-354D | 500 | 400 | 594 | 475 |
| AP-354E | 600 | 480 | 713 | 570 |
| AP-354F | 670 | 536 | 775 | 620 |
|
