| Categories | Marine Diesel Genset |
|---|---|
| Brand Name: | Hosem Power |
| Model Number: | A-C41M |
| Certification: | CE/ISO9001 |
| Place of Origin: | CHINA |
| MOQ: | 1 SET |
| Price: | $6000-$7000 |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 500 unit per month |
| Delivery Time: | 30 days |
| Packaging Details: | ply-wood or plastic film |
| Production Name: | Power Generatoring Set |
| Frequency: | 50Hz/ 60Hz |
| Standby Output: | 33kW |
| Prime Output: | 30kW |
| Engine Brand: | Cummins |
| Engine Model: | 4BTA3.9-G2 |
| Alternator Brand: | Stamford |
| Alternator Model: | PI 144J |
| Voltage: | 230V/400V |
| Controller: | Deepsea/ ComAp/ Smartgen |
Specification:
| Engine | |
| Model | 4BTA3.9-G2 |
| Type | 4 Cylinders In-line |
| Bore X Stroke (mm) | 102*120 |
| Displacement(L) | 3.9 |
| Compression ratio | 16.5:1 |
| Rated speed(rpm) | 1500/1800 |
| 100% load fuel consumption(L/H) | 6 |
| Lube oil capacity(L) | 11 |
| Starting method | D.C. 24V Electric starting |
| Alternator | |
| Model (Marathon) | Stamford |
| Model (Stamford) | PI 144J |
| Rated voltage(V) | 230/400 |
| Rated current | According to the selected voltage and phase |
| Rated frequency(Hz) | 50/60 |
| Rated speed(rpm) | 1500/1800 |
| Phase | 3 |
| Winding connection | 4 - wire connection, Y type |
| Excitation method | Brushless |
| Starter battery capacity(Ah) | 90*2 |
| Starter battery voltage(V) | 24 |
| Power factor | 0.8 |
| Steady-state voltage reguation | ±1.0% |
| Temperature class | H |
| Insulation class | H |
| Voltage regulation | AVR |
OPTIONAL EQUIPMENT
Feature:
The generator can be used as a main marine generator, marine emergency generator, or harbor generator, ccs, be approved.
Cooled by the heat exchanger and seawater pump. Adopt Cummins engine with twin high-pressure fuel pipe and fuel leakage alarming system.
1. Power Range: 15-140kw
2. Engine: Cummins
3. Alternator: Genuine Stamford, Marathon, Meccalte, etc
4. Controller: Deepsea or Smartgen with or without AMF. Digital display of parameters of diesel engine, and integration of measuring and monitoring.
Options: Remote monitoring of running parameters.
5. Color: Can be customized
FAQ
Q: Do you offer OEM service?
A: Yes
Q: What is your payment term?
A: 30% T/T in advance, 70% balance when receiving B/L copy, Or 100%
irrevocable L/C at sight.
Q: What is your lead time?
A: About 20-30 days after receiving advance deposit or original
L/C.
Q: What warranty do you provide?
A: One year, during the guarantee period, we will supply free of the easily damaged parts for the possible problems except for
the incorrect operation. After expiration, we supply cost spare parts for Genset maintenance.
|
