Name: 7kW AC EV Charger with Type1Type2GBT Plug and RFID
Brand: KIWI
Price: 270 USD

Home >

7kW AC EV Charger with Type-1/Type-2/GB/T Plug and RFID

Categories	AC EV Chargers
Place of Origin:	Guangdong, China
Model Number:	S1-AC220V-7KW
Brand Name:	KIWI
MOQ:	2
Price:	$270-320
Output Power:	7 kW
Input Voltage:	200 - 220v
Interface Standard:	Type-1/Type-2/GB/T
IP Protection:	IP55
OCPP Version:	OCPP 1.6J/1.5J
User Interface:	3.8 inch LCD or LED
Communication Protocols:	Proprietary and OCPP 1.6J/2.0.1
RFID Reader:	ISO/IEC 14443 A/B Mifare RFiD reader
Rated Power:	7KW、11KW、22KW
Size:	202104388mm
Weight:	6kg(Without column)
Input Current:	Each phase 0~32A
Output Voltage:	AC 220V±20%
Output Current:	Each phase 0-32A
Operating Temperature:	-35°C to +50°C

Contact Now

Add to Cart

Product Details
Company Profile

7kW AC EV Charger with Type-1/Type-2/GB/T Plug and RFID

Item	Specification
Installation Method	Wall-mounted, column (optional)
Rated Power	7KW、11KW、22KW
Charging mode	APP(QRCode)、Plug &Charge、RFID
*Size (H W * D)**	202104388mm
Weight	6kg(Without column)
Input
Input voltage	230VAC/400 VAC/400 VAC
Input Current	Each phase 0~32A
Leakage Protection	overcurrent, overvoltage, undervoltage, ground fault, integrateed surge protection, RDC (typeA + DC6mA), over-temperature protection
Output
Output voltage	AC 220V±20%
Output current	Each phase 0-32A
Connection method
Number of plug	1
Charging connection method	1、Connection method C (plug version) 2、Connection method B (socket version)
Plug wire length	5m(customizable)
Plug standard	Type-1/Type-2/GB/T
Human-computer interaction
LED	LED Status light

Other
Protection level	IP55
Operating temperature	-35°C to +50°C
Relative humidity	<95%，No condensation
Lifespan	≥10000 times

Customers Also LIke to Ask These Questions

Q: How is your electric vehicle charging station after-sale service?

A:1/We will build a whatsapp/skype/wechat service group with technical engineers and company leader if need;

2/We provide 24/7 online service,so you're welcome to contact us any time you need;
3/Will change the part for free during warranty if non-human damage,for other problems,we'd like to supply customer the part at original cost.

Q: How is your payment method?

A: Same as other ev charging stations suppliers,normally 30%-50% deposit and balance paid off before shipment,special requirement customer please contact us for further discussion.

Q: How long is your normal delivery time?

A: 1/For stock ev charger,can arrange the shipment immediately after you confirm the order;
2/For custom AC ev charger less than 100pcs,normally 7-15 days;
3/For custom DC ev charger less than 100pcs,normally 15-25 days;

Q: Can I use my own card or app at your electric car charging stations?

A: Normally the RFID card and app have to identify our electric charger,so we will provide you 3 free RFID card for each

charger.

Q:Will your electric car charger charging slower in winter?

A:The electric charging station may need a little longer warm up time before normal run,but this is very small change,it won't influence the output power,so we can ignore this influence.

Q:Can you provide a video how to install the electric vehicle charger?

A:Yes we have the installation guide video,it's very easy and anyone who know a little about electricity safety can finish this work,we will also be ready online to help your any possible question.

Q:How can I become your exclusive agency?
A:Only if you have this interest,you can be our agent if we don't have exclusive agent in your market.
if you want to be exclusive agent,we will have an annual sales amount target requirement,welcome to further discuss about more details,we're open to any constructive advice.
