| Categories | Ultra Low Frequency Antenna |
|---|---|
| Brand Name: | chaowei |
| Model Number: | CW-F017 |
| Certification: | BSCI CE Fcc RoHS Trade Mark Patent ISO9001:2008 |
| Place of Origin: | Guangdong China |
| MOQ: | 10-100 pcs |
| Price: | negotiable |
| Payment Terms: | T/T and other payments can also be negotiated. |
| Supply Ability: | 50000 Pieces per Month |
| Delivery Time: | 1-7 work days |
| Packaging Details: | 1Piece/Bag |
| Antenna Name: | FRP antenna 440-450mhz high gain outdoor waterproof antenna SMA connector |
| Frequency range: | 440-450MHz |
| Gain: | 2dBi |
| VSWR: | ≤2.0 |
| Power: | Polarization |
| Input connector type: | SMA male or Request |
| Antenna color: | white or request |
| Antenna size: | 400mm |
| Operating temperature: | -45~85℃ |
Fiberglass Ultra Low Frequency Antenna 450mhz High Gain Outdoor Waterproof
Fiberglass antenna 440-450mhz high gain outdoor waterproof antenna SMA connector
Electrical Mechanical Specifications
| Electrical Specifications | |
| Frequency Range, MHz | 440-450 MHz |
| Gain, dBi | 2.0 dBi |
| VSWR | ≤2.0 |
| Polarization | vertical |
| Horizontal Beamwidth | 360° |
| Vertical Beamwidth | 120° |
| Input Impedance | 50 Ω |
| Max. Input Power | 50 W |
| Lightning Protection | DC Ground |
| Mechanical Specifications | |
| Connector | SMA male |
| Dimensions | Ø400x19.0 mm |
| Weight | 0.55 kg |
| Color | White |
| Radome Material | ABS (UV Stabilized) |
| Operating Temperature | -40°C to +65 °C |



|
